BTS 350

bts-350
bts-350

BTS 350


download brochure

Request For Quote

  • Overview
  • Benefits
  • Technical Specifications

Overview

  • Continuous access to samples, reagents, and cuvettes without interrupting the testing process.
  • Up to two hours walk-away time
  • Dilutions and re-analysis, when necessary, are fully automated
  • Real-time quality control program with multiple Westgard rules
  • Real-time monitoring of reagent usage, lot follow-up
  • Kinetics by Linear Regression
  • PC Communication Software
  • Power only 30 W

Benefits

  • LEDs: The BTS-350 is truly a new generation in the class of semi-automatic analyzers as it is the only analyzer with a complete range of LEDs optimized for Biochemistry and Turbidimetric assays.
  • The LEDs not only have low energy consumption, they also have a practically unlimited lifetime.
  • HCF: Incorporating state-of-the-art optics with an innovative design, the BTS-350 has Hard Coated Filters with extensive lifespan and an optical system designed to optimize measurements for both Biochemistry and Turbidimetric assays.
  • Minimal Energy Consumption and Low Maintenance: In conjunction with the     LEDs and HCF, the BTS-350 is designed to avoid frequent parts replacement and consumes negligible energy.
  • Consequently, both operation and maintenance cost is kept low.
  • Advanced Ergonomic Design: In addition, the BTS-350 is equipped with a very sensitive aspiration pulse sensor directly at the back of the reaction tube allowing easy manipulation of different samples.
  • Power Failure Protection: The BTS-350 is designed with the use anywhere anytime concept in mind. The instrument is supplied with an Optional Battery Pack that is charged automatically when the instrument is connected to a normal electrical feed and provides 2hrs of back-up energy for those critical times when there is no electricity

Technical Specifications


  • Optical Systems: Range of measurement: 0-3.5 A all wavelengths
  • Wavelengths: 340, 405, 505, 535, 560, 600, 635, 670 nm Plus 3 free positions for optional filter
  • Semi Half Bandwidth: 5 nm ± 1 nm
  • Light Source: LEDs
  • Settings: monochromatic and bichromatic
  • Thermostat System: Peltier system from 25-40 o C
  • Fluidic SystemContinuous flow system with peristaltic pump incorporated Stepper motor pump operation Sipping volume can be programmed from 100 μl to 5 ml Automatic adjustment of sample volume Automatic adjustment of sample position
  • Cuvettes Flow: Cuvette of 18 μl
  • Removable Cuvette: macro, semi-micro and micro Round tubes with 12 mm Printer Screen and Keyboard: Thermic printer
  • Screen: graphic LCD lighted screen 320 x 240 px
  • Keyboard: tactile membrane
  • Methods of Calculation: Absorbance End Point Kinetic Differential Mode Fixed Time Ratiometric Mode Cut Off CALIBRATION Factor Calibrator Calibration
  • Curve Calibration: CURVE Up to 8 Calibration points Up to 3 replicates per point
  • Axis: Linear and log
  • Calculation Functions: spline, linear regression, quadratic regression, polygonal
